Additional Information
| Interface Options | Ethernet, Parallel, Serial (RS-232), USB |
|---|---|
| Manufacturer AIDC | Zebra |
| Max Roll Outer Diameter | 8 |
| Model Name | ZM400 |
| Print Resolution | 203 dpi |
| Print Speed | 10 ips |
| Printer Type | Industrial |
| Printing Technology | Thermal Transfer |
| Ribbon Core Size | 1 inch |
Zebra ZM400 Specs
Technical Information
- Maximum Mono Print Speed: 10 in/s
- Maximum Print Resolution: 203 dpi
- Print Color: Monochrome
- Maximum Print Width: 4.09"
- Recommended Use: Label Print
- Barcode Symbology Supported:
- Codabar
- Code 11
- Code 128-A
- Code 128-B
- Code 128-C
- UCC Case Codes
- Code 39
- Code 93
- EAN-13
- EAN-8
- Industrial 2 of 5
- Interleaved 2 of 5
- LOGMARS
- MSI
- Planet Code
- Plessey
- POSTNET
- Standard 2 of 5
- UPC 2 or 5 Digit Extension
- EAN With 2 or 5 Digit Extension
- UPC-A
- UPC-E
- Aztec Code
- Codablock
- Code 49
- Data Matrix
- Maxi Code
- QR Code
- PDF-417
- Micro PDF-417
- RSS
General Information
- Product Type: Direct Thermal/Thermal Transfer Printer
- Product Series: Z Series
- Brand Name: Zebra
- Manufacturer: Zebra Technologies Corporation
- Product Model: ZM400
- Product Name: ZM400 Network Thermal Label Printer
Physical Characteristics
- Height: 13.3"
- Width: 10.9"
- Depth: 18.7"
Interfaces/Ports
- USB: Yes
- Serial Port: Yes
- Parallel Port: Yes
Other
- Platform Supported: PC
- Package Contents:
- ZM400 Network Thermal Label Printer
- Power Cord with US plug
- Driver and Software CD
- Safety Guide
- ZM400 Network Thermal Label Printer
- Power Cord with US plug
- Driver and Software CD
- Safety Guide
- Additional Information:
- RFID Ready
- Auto-calibration
- Real Time Clock
- 32-bit processor
- Unicode - Compliant
- Color-coded operator cues
- Quick change printhead and platen
- Standard Ribbon coated-out spindle
- Multi-lingual backlit 240x128 pixel graphic display
- Element Energy Equalizer (E3) (for print head energy control)
- 7 bitmapped and 1 scalable font (CG Triumvarate Bold Condensed)
Media Types & Handling
- Maximum Label Width: 4.25"
- Maximum Label Length: 39"
- Media Type:
- Continuous Form
- Die-cut Label
- Tag Stock
- Black Mark
- Fanfold
- Notched
- Perforated Label
- Media Thickness: 10 mil
- Media Sensor:
- Reflective Media Sensor
- Transmissive Media Sensor
- Label Core Size: 3"
- Ribbon Core Size: 1"
- Maximum Roll Diameter: 8"
Power Description
- Input Voltage:
- 110 V AC
- 220 V AC
Memory
- Standard Memory: 16 MB
- Memory Technology: DRAM
- Flash Memory: 8 MB
Network & Communication
- Ethernet: Yes
- Ethernet Technology: Fast Ethernet
Warranty
- Limited Warranty: 1 Year
Fonts & Emulation
- Language Emulation: EPL
